Concealed Solution for Limited Installation Depth

July 29, 2025

In modern bathroom design, every centimetre matters – especially when the depth of the wall is limited. That’s exactly where the LIV-FIX WC 9052 comes into play: our slimmest concealed cistern, specifically designed for spaces where standard solutions are not suitable.

Whether it’s the renovation of older buildings, narrow partition walls or sanitary units in public facilities – this model delivers maximum functionality in minimal space.

Why LIV-FIX WC 9052?

Extremely small installation depth
With an adjustable range of 91 to 140 mm, this model is the ideal solution for shallow drywall constructions or narrow masonry niches. The exact depth depends on the specific installation situation and the project requirements – such as pipe alignment, wall flush mounting, or adapting to existing structures. The depth is typically defined by the planner or installer based on the real-life scenario.
Technical advantages and key functionalities
✔ Robust and durable construction,
✔ Pre-mounted fixing elements and adjustable support legs (0–190 mm),
✔ Dual flush (3/9 L),
✔ Adjustable flushing volume (large flush: 7–9 L, small flush: 3–6 L),
✔ Silent mechanical filling valve (noise emission class 1, ISO 3822),
✔ Fully insulated against condensation,
✔ Pre-mounted angle valve (top center, water connection G 1/2),
✔ Depth-adjustable drain elbow (+/-10 mm).

You can watch the assembly process on our YouTube channel.

Wide Selection of Flushing Plates

In bathroom design, it’s often the details that make the difference – and the flushing plate is one of the key visual elements. The LIV-FIX WC 9052 is compatible with a wide range of flushing plates that offer both functional and aesthetic flexibility.

Ruby, Caro, Zircon, Circle – soft and geometric shapes,
Beat, Key, Tune – contemporary and minimalist designs,
Aplite Duo, Dots Duo, Selenite Duo, Ovate Duo – classic elegance.

You can choose between various materials and finishes – from minimalistic gloss to brushed metal textures.

Note: The flushing plate must be ordered separately, allowing full customization of your bathroom look.

Solutions for Every Space

At Fluidmaster, we offer a full range of concealed cisterns – each one tailored to meet specific spatial requirements (as described in our blog post Various Concealed Cisterns for Different Needs):

STANDARD: LIV-FIX WC 9012 – a versatile, universal model,
SLIM: LIV-FIX WC 3800 – designed for narrow installation widths,
THIN: LIV-FIX WC 9052 – ideal for installations with reduced wall depth,
LOW: LIV-FIX WC 6052 – perfect for low height constraints (e.g., under windows, in attics).

Each model is designed with functionality, long-term use, and complete aesthetic harmony with modern bathrooms in mind.

Aesthetic, Functional and Reliable

LIV concealed systems are not just technical solutions – they are part of modern bathroom architecture. With a variety of flushing plates in different colours, materials and designs, you can fine-tune your bathroom down to the last detail.

In addition, every LIV concealed cistern offers:

✔ Long lifespan (10-year warranty, 25-year availability of spare parts),
✔ Quiet but efficient operation for everyday comfort,
✔ Easy maintenance through the service opening,
✔ Water-saving flushing with adjustable volumes.

Conclusion

If you’re planning a bathroom where wall depth limits your equipment choices, the LIV-FIX WC 9052 is your ideal solution. Its ultra-slim build, combined with the full feature set of standard models, provides a technically sound and aesthetically refined answer – without compromise.

Choose a slim, yet fully equipped concealed system that fits seamlessly into even the most demanding spaces.

Pro Tip

When planning the installation, make sure to verify the available wall depth and the layout of drain and water connection pipes – to fully utilise the potential of this system in collaboration with your project planner or installer.
